Research Article
Evaluation of CCD cameras for beam profile monitoring with high intensity particle beams traversing gases
1
Physik Department, Technical University Munich, 85748, Garching bei München, Germany
2
Excitech GmbH, 26419, Schortens, Germany
Received:
24
September
2019
Accepted:
29
November
2020
Published online:
19
December
2020
Measurements of the absolute sensitivity of three different optical cameras are presented. An absolutely calibrated tungsten strip-lamp was used for calibrating the devices. An experimental method for determining the solid angle which is accepted by the combination of the cameras with a broadband apochromatic lens is described. The results with five bandpass filters between 337nm and 740nm are shown. The signal to noise ratio and the spatial resolution of the camera systems is also discussed.
PACS: 07.60.-j – / 42.30.-d – / 42.79.Ls – / 42.79.Pw –
Key words: Optical instruments and equipment / Imaging and optical processing / Scanners / Image intensifiers / Image converters / Imaging detectors and sensors
